Thermoforming Protective/Masking
Compostable
Thermoforming Protective/Masking
Greendot's Thermoformable Protective Film is a designed film in which the adhesive system and the film are extruded simultaneously. It can readily tolerate temperatures of up to 190° C without tearing thanks to its incredibly strong temperature resistance. Thermoformable Protective Film can be removed without leaving any adhesive residue on the surface it is protecting.
Thermoforming Protective/Masking characteristics
Zero Damage
prevents any harm to the substrate coating and protected surface.
Easily Removeable and Sealable
smoothly comes on and off of protected substrate.
100% Recyclable & Eco-Friendly
Polyethylene is easily recycled, without releasing any harmful substances into the environment.
Protection from High Temperatures
is appropriate for high-temperature thermoforming operations on plastic and metal sheets.
Puncture- and Tear-resistant
Maximum security is provided by high rip resistance around jagged edges and corners, as well as during substrate machining and film removal.
Wrinkle-Free
The product maintains its uniform coverage on the masked surface and is free of creases and wrinkles.
Leaves No Traces
After the film is removed, there are no signs of glue left behind on the surface that was shielded.
Thermoforming Protective/Masking Specification
| ATTRIBUTE | SI | FPS |
|---|---|---|
| Thickness | 30- 80 µ | 1.18 – 3.14 mil |
| Width | 100 – 2800 mm | 3.93 – 110.23 in |
| Roll Length | As per requirement | |
| Color | Transparent/Opaque in any color/Tinted color | |
| Printing | 2 Colors | |
| Available cores for film winding | Paper core, Plastic core, Metal core | |
Technical Properties
| Property | SI | FPS | Test Method | |
|---|---|---|---|---|
| Tensile Strength | MD | 14 N/mm² | 2030 psi | ASTM D 882 |
| TD | 10 N/mm² | 1450 psi | ||
| Elongation | MD | 300% | 300% | |
| TD | 500% | 500% | ||
| Tear Strength (Elmendorf) | MD | 150 gm | 0.33 lbf | ASTM D 1922 |
| TD | 500 gm | 1.10 lbf | ||
| Peeling Strength @60° C | 0.50 – 2.00 (N/25mm) | 2.85 – 11.4 (lbf/inch) | ||
| Peeling Strength @180° C | 0.80 – 2.50 (N/25mm) | 4.56 – 14.3 (lbf/inch) | ||
Application of Thermoforming Protective/Masking
Plastic Sheet & Molded Components
Glass
White Goods
Metal
Automotive
